2019 Vol.21, Issue 1 Preview Page

Research Paper

Durability evaluation depending on the insert size of conical Picks by the field test

삽입재 크기에 따른 코니컬 커터의 현장 내구성 평가 연구

Soon-Wook Choi1*
최 순욱1*
1Senior Researcher, Department of Infrastructure Safety Research, Korea Institute of Civil Engineering and Building Technology
1정회원, 한국건설기술연구원 인프라안전연구본부 수석연구원
* Corresponding Author
31 January 2019. pp. 49-59
PDF XML Citation
Abstract

In this study, the durability of conical pick cutter was compared and analyzed by pre- and post-test visual inspection, measurement of weight loss and wear volume through field test on two types of conical pick cutters applied to rotary drum cutter. In the visual inspection, it was found that only 9 inserts were lost in the slim type conical pick cutter. This result show that the thickness of the head cover surrounding a insert was important to maintain the insert during excavation. The weight loss and wear volume of the heavy type conical pick cutter were less than half that of the slim type. From these results, it can be confirmed that heavy type is more useful than slim type in hard rock. It should be noted that, when determining the wear loss of the conical pick cutter, the mutual comparison of the weight measurement and the wear volume measurement results may be different due to the unit weight of the material and the spalling caused by excavation.

Keywords
Conical picks
Insert size
Wear
Weight loss
Abrasion volume

본 연구는 로터리드럼커터에 적용된 두 종류의 코니컬 픽커터에 대한 현장시험을 통해 시험 전과 후의 육안조사와 중량감소 및 마모부피를 측정하여 코니컬 픽커터의 내구성을 비교 ‧ 분석하였다. 육안조사를 통해 슬림 타입 코니컬 픽커터에서만 총 9개의 삽입재 손실이 나타남을 확인하였고 삽입재 보호를 위해 두부의 두께가 중요함을 알 수 있었다. 시험 전과 후의 픽커터의 중량손실과 마모부피는 헤비타입이 슬림타입에 비해 반이하로 작게 나타나 경암반에서 헤비타입이 더 유용함을 확인할 수 있었다. 픽커터의 마모손실을 판단할 때, 중량측정과 마모부피 측정결과의 상호 비교는 재료의 단위중량과 굴착에 의한 스폴링에 의해 차이가 나타날 수 있으므로 주의해야 할 것으로 판단된다.

키워드
코니컬커터
삽입재 크기
마모
중량손실
마모부피
References
1
Choi, S.W., Chang, S.H., Lee, C., Lee, G.P., Bae, Y.H., Ha, T.W. (2015), "Performance evaluation of conical picks for roadheader in copper mines", Tunnel and Underground Space, Vol. 25, No. 6, pp. 496-504.
10.7474/TUS.2015.25.6.496
2
Choi, S.W., Chang, S.H., Lee, G.P., Park, Y.T. (2014a), "Performance estimation of conical picks with slim design by the linear cutting test (I): depending on attack angle variation", Journal of Korean Tunnelling and Underground Space Association, Vol. 16, No. 6, pp. 573-584.
10.9711/KTAJ.2014.16.6.573
3
Choi, S.W., Chang, S.H., Lee, G.P., Park, Y.T. (2014b), "Performance estimation of conical picks with slim design by the linear cutting test (II): depending on skew angle variation", Journal of Korean Tunnelling and Underground Space Association, Vol. 16, No. 6, pp. 585-597.
10.9711/KTAJ.2014.16.6.585
4
Choi, S.W., Kang, T.H., Chang, S.H., Lee, C., Lee, G.P., Kim, C.Y. (2016), "Performance estimation depending on the insert size of conical picks by linear cutting test", Journal of Korean Tunnelling and Underground Space Association, Vol. 18, No. 2, pp. 221-233.
10.9711/KTAJ.2016.18.2.221
5
Copur, H., Ozdemir, L., Rostami, J. (1998), "Roadheader applications in mining and tunneling industries", SME Annual Meeting, Preprint No: 98-185, pp. 1-6.
6
Fowell, R.J., Ochei, N.N. (1984), "A comparison of dust make and energy requirements for rock cutting tools", International Journal of Mining Engineering, Vol. 2, No. 1, pp. 73-83.
10.1007/BF00880859
7
Goktan, R.M., Gunes, N. (2005), "A semi-empirical approach to cutting force prediction for pointattack picks", The Journal of The South African Institute of Mining and Metallurgy, Vol. 105, No. 4, pp. 257-264.
8
Hurt, K.G., Evans, I. (1981), "Point attack tools: an evaluation of function and use for rock cutting", Mining Engineer, Vol. 140, No. 234, pp. 673-675.
9
Kim, E., Rostami, J., Swope, C. (2012), "Full scale linear cutting experiment to examine conical bit rotation", Journal of Mining Science, Vol. 48, No. 5, pp. 882-895.
10.1134/S1062739148050139
10
Park, Y.T., Choi, S.W., Park, J.H., Lee, C.H., Chang, S.H. (2013), "Excavation mechanism of roadheader and statistical analysis of its key design parameters based on database", Tunnel and Underground Space, Vol. 23, No. 5, pp. 428-441.
10.7474/TUS.2013.23.5.428
11
Pichler, J. (2011), Mechanical excavation of tunnels with Roadheaders, Lecture note, Post graduate master course - Tunnelling and Tunnel Boring Machine, Politecnico Di Torino, pp. 1-78.
21671729
12
Rojek, J., O-ate, E., Kargl, H., Labra, C., Akerman, J., Restner, U., Lammer, E., Zarate, F. (2008), "Prediction of wear of roadheader picks using numerical simulations", Geomechanik und Tunnelbau: Geomechanik und Tunnelbau, Vol. 1, No. 1, pp. 47-54.
10.1002/geot.200800005
13
Tatiya, R.R. (2005), Surface and Underground Excavations-Methods, Techniques and Equipment, A.A. Balkema Publishers, London, pp. 237-244.
10.1201/9781439834220
14
Tunnel Business Magazine (2011), Roadheaders in Hard Rock-East Side Access Among North American Projects Employing Roadheader Technology, February 2011, pp. 20-21.
Information
  • Publisher :Korean Tunneling and Underground Space Association
  • Publisher(Ko) :한국터널지하공간학회
  • Journal Title :Journal of Korean Tunnelling and Underground Space Association
  • Journal Title(Ko) :한국터널지하공간학회 논문집
  • Volume : 21
  • No :1
  • Pages :49-59
  • Received Date : 2018-10-15
  • Revised Date : 2018-11-13
  • Accepted Date : 2018-11-16
  • DOI :https://doi.org/10.9711/KTAJ.2019.21.1.049
